RSD-GE Series
Unleash The
Power of Pressure
with Our
Plunger Pumps
The RSD-GE pumps are highly versatile, capable of efficiently operating at a maximum pressure of 200 bar and handling water temperatures of up to 65°C (150F). This particular version is equipped with a flange designed for coupling with a combustion engine, making it an ideal choice for professional high-pressure washers. It excels in situations where a reliable electricity supply is limited, ensuring efficient operation.
Suitable application for RSD-GE Series :
Pressure Washer
Municipal Cleaning
Technical Specification
Weight (Kg)
8.4
Oil Capacity (Ltr.)
0.4
Inlet (Inch)
1/2″
Outlet (Inch)
3/8”
Material
Power End : Aluminum
Liquid End : SS 304
Liquid End : SS 304
Discover all the variants in the series RSD-GE.
| Pump Code | Pump Model | MAX. PRESSURE | MAX. VOLUME | RPM | MAX. POWER | Shaft Ø Inch | |||
|---|---|---|---|---|---|---|---|---|---|
| BAR | PSI | l/min | GPM | 60 Hz | HP | KW | |||
| 751097 | RSD9521GR | 210 | 3050 | 9.5 | 2.5 | 3400 | 5.1 | 3.7 | 3/4 |
| 751098 | RSD9521GL | 210 | 3050 | 9.5 | 2.5 | 5.1 | 3.7 | 3/4 | |
| 751099 | RSD1121GR | 210 | 3050 | 11.4 | 3.0 | 6.1 | 4.5 | 3/4 | |
| 751100 | RSD1121GL | 210 | 3050 | 11.4 | 3.0 | 6.1 | 4.5 | 3/4 | |
